TrueNAS Mini Series · 10 GbE Desktop NAS

TrueNAS Mini X

Drive Bays: 6 × 3.5″ / 2.5″ hot-swap bays
Processor: Intel Atom C3758R 8-core 2.4 GHz
Memory: 16 GB ECC DDR4 (expandable to 64 GB)
Networking: 2 × 10 GbE SFP+ (standard)
OS: TrueNAS SCALE (Linux-based, open source)
Max Raw Capacity: Up to 108 TB (6 × 18 TB)

Request Pricing View Datasheet

Overview

The TrueNAS Mini X brings 10 GbE networking to the desktop NAS form factor as standard equipment — no optional add-in card required. Where the Mini E+ delivers up to 2 Gbps with LACP-bonded 1 GbE links, the Mini X delivers up to 10 Gbps from each of its two SFP+ ports, making it the right choice for environments where a workstation, NVR server, or hypervisor host needs sustained high-bandwidth access to shared storage.

Six hot-swap 3.5″ bays and two M.2 NVMe slots support L2ARC read cache and ZIL/SLOG write log acceleration. The Intel Atom C3758R 8-core processor handles concurrent SMB, NFS, iSCSI, and container workloads without CPU saturation. TrueNAS SCALE runs all of it from a polished browser UI — open source, no per-seat licensing, and a full application catalog for Plex, Nextcloud, MinIO, and more.

Features and Benefits

What makes the TrueNAS Mini X the right step up from entry-level desktop NAS.

Networking and Performance

10 GbE Standard — No Upgrade Card Required

The TrueNAS Mini X ships with two 10 GbE SFP+ ports as standard equipment. Connect directly to a 10 GbE switch or use DAC cables for direct workstation attachment — giving every client on the network access to Mini X throughput at full line rate. For environments running 4K video editing, VM storage, or high-ingest backup targets, 10 GbE standard is the difference between a storage bottleneck and headroom to grow.

8-Core Processor

The Intel Atom C3758R 8-core 2.4 GHz processor handles concurrent SMB, NFS, iSCSI, encryption, and containerized application workloads simultaneously without becoming the CPU bottleneck that limits throughput on lower-core-count desktop NAS platforms.

M.2 NVMe Cache Slots

Two M.2 NVMe/SATA slots support dedicated L2ARC read cache and ZIL/SLOG synchronous write acceleration. Adding NVMe cache dramatically improves random read performance and database/VM write latency without consuming any of the 6 primary drive bays.

Data Protection

OpenZFS End-to-End Checksums

Every block written to the Mini X carries a cryptographic checksum. ZFS verifies the checksum at read time and repairs corrupted blocks from redundant copies before returning data to the client — silent corruption is impossible.

RAID-Z1, Z2, and Mirrors

Six bays support RAID-Z1 (1 parity, 5 data), RAID-Z2 (2 parity, 4 data), or a 3-drive mirror pair with a hot spare. OpenZFS RAID is software-defined with no proprietary RAID controller required.

Instant Snapshots

Create per-dataset ZFS snapshots in milliseconds on a configurable schedule. Snapshots are immutable — ransomware and accidental deletion cannot touch a snapshot that has already been taken.

Cloud Sync and ZFS Replication

Push encrypted snapshots to Amazon S3, Backblaze B2, Azure, or any S3-compatible target. Replicate datasets to a remote TrueNAS over encrypted ZFS replication for 3-2-1 backup without third-party software.

Software and Applications

TrueNAS SCALE

Linux-based, open-source NAS OS from TrueNAS. Full-featured browser UI, REST API, Active Directory and LDAP integration, VAAI-certified VMware support, and TrueCommand multi-system management — all included at no software licensing cost.

App Catalog (Docker / Kubernetes)

Deploy Plex Media Server, Nextcloud, Vaultwarden, MinIO object storage, Syncthing, and hundreds of containerized apps directly on the Mini X — isolated from storage workloads in Kubernetes-managed containers.

Active Directory Integration

Join the Mini X to existing Windows Active Directory domains. SMB share permissions are controlled through AD groups — no separate NAS user management required for domain-joined environments.

IPMI Out-of-Band Management

Dedicated IPMI LAN port provides remote power control and KVM-over-IP console access regardless of OS state — manage the Mini X from anywhere without requiring physical access to the appliance.

View all features in the datasheet

Authorized TrueNAS Reseller

More than a price tag

The Mini X ships diskless — drive selection, memory configuration, and M.2 cache sizing are all decisions worth talking through before you order. Tell us your workload and we’ll configure the right build.

Configuration guidance from people who know TrueNAS
Authorized-reseller pricing, without the procurement friction
Order follow-through — from PO to delivery

Talk to a Specialist View Datasheet

Technical Specifications

Hardware metrics from the official TrueNAS datasheet.

Platform

TrueNAS Mini X
Operating System

TrueNAS SCALE (Linux-based, open source)
Form Factor

Desktop / Tower
Processor

Intel Atom C3758R, 8-core 2.4 GHz (Denverton)
Memory

16 GB ECC DDR4-2400 SODIMM (2 slots, max 64 GB)
Drive Bays

6 × 3.5″ SATA hot-swap; max raw ~108 TB
Cache / Log

2 × M.2 NVMe/SATA slots (L2ARC + ZIL/SLOG)
Boot Device

Dual internal USB (mirrored OS boot)

Onboard 10 GbE

2 × 10 GbE SFP+ (standard, no upgrade required)
Protocols

SMB/CIFS, NFS v3/v4, iSCSI, FTP, WebDAV, S3-compatible

Form Factor

Desktop (tower)
Power Supply

Internal PSU
Operating Temperature

32°F to 95°F (0°C to 35°C)
Rear Ports

2 × USB 3.0, 1 × USB 2.0, 1 × HDMI, 2 × 10 GbE SFP+, 1 × IPMI LAN

Filesystem

OpenZFS (checksumming, RAID-Z1/Z2/Z3, snapshots, replication)
Directory Services

Active Directory, LDAP, Kerberos, NIS
Management

Browser-based WebUI, REST API, CLI; IPMI out-of-band
Applications

TrueNAS SCALE app catalog (Plex, Nextcloud, MinIO, and more)
Cloud Replication

Amazon S3, Backblaze B2, Azure Blob, Google Cloud, Wasabi, all S3-compatible

View datasheet for full specs

Compare TrueNAS Mini Series Models

Select the right scale for your storage workload.

TrueNAS Mini Series model comparison by throughput, capacity, and networking.
Model	Max Throughput	Max Raw Capacity	Networking	Action
TrueNAS Mini E	Up to 2 Gbps (LACP)	Up to 72 TB raw	2 × 1 GbE	View
TrueNAS Mini E+	Up to 2 Gbps (LACP)	Up to 108 TB raw	2 × 1 GbE + opt 10 GbE	View
TrueNAS Mini R	Up to 10 Gbps	Up to 144 TB raw	2 × 10 GbE SFP+	View
TrueNAS Mini X This model	Up to 10 Gbps	Up to 108 TB raw	2 × 10 GbE SFP+	Current
TrueNAS Mini X+	Up to 10 Gbps	Up to 144 TB raw	2 × 10 GbE SFP+	View
TrueNAS Mini XL+	Up to 10 Gbps	Up to 216 TB raw	2 × 10 GbE SFP+	View

Mini X+ vs Mini R: deeper buyer guide

Frequently asked questions

The TrueNAS Mini X is a 5-bay compact desktop NAS with 2× 10 GbE SFP+ networking (standard, not optional), ECC RAM, and up to 108 TB capacity. Sits between the entry Mini E+/E and the higher-spec Mini X+.

The Mini X+ adds two M.2 NVMe bays (5+2 total vs 5), and tops out at 110 TB vs the Mini X's 108 TB. The M.2 bays on the X+ let you use NVMe cache (L2ARC + ZIL) for faster small-file performance.

Up to 108 TB raw across 5 drive bays. The Mini E+ has the same 108 TB ceiling but at 1 GbE baseline networking; the Mini X has 10 GbE SFP+ standard.

Yes — 2× 10 GbE SFP+ is standard on the Mini X (and X+ and XL+). On the Mini E and E+ tiers, 10 GbE is either absent or optional.

Pro media editorial workstations, design studios, small departments needing 10 GbE without rack space. Same data-integrity guarantees (ECC + OpenZFS) as the rest of the Mini Series.
