TrueNAS H20
- Controller: 10 Core (20 Threads)
- Memory: 128–256 GB RAM
- Read Cache: 2× 3.2 TB NVMe SSD
- Networking: 4× 1G Base-T + up to 4× 10/25 GbE
- Fibre Channel: 2× 16 Gb
- Max Throughput: 4 GB/s
- Max Raw Capacity: 3 PB
Overview
The TrueNAS H20 delivers the comprehensive feature set of TrueNAS Open Enterprise Storage, including High Availability (HA), at an entry-level price point. Designed for small and medium businesses, the H20 offers optional dual controllers, hybrid or all-flash configurations, and NVMe support in every bay for low-latency workloads.
With double the cores and cache of the H10, the H20 scales performance and reliability in a compact 2U footprint, supporting expansion shelves up to 3 PB raw capacity. The simplified web-based interface and robust feature set, coupled with the absence of additional licensing costs, make the H20 an accessible yet powerful option for growing businesses handling media storage, VM hosting, and video surveillance workloads.
Features and Benefits
The capabilities that make the TrueNAS H20 a powerful mid-range hybrid storage platform for growing SMB and edge environments.
Performance and Data Integrity
Scalable Performance & Capacity — 4 GB/s with Dual NVMe Cache
Self-Healing Data Protection
Unlimited Snapshots & Replication
Connectivity and Protocols
4× 1G Base-T Onboard
Up to 4× 10/25 GbE Optional
2× 16 Gb Fibre Channel
Unified File, Block & Object
Enterprise Management
High Availability (HA) — Optional Dual Controller
Intelligent Storage Optimization
Enterprise-Grade Efficiency
More than a price tag
Sizing the TrueNAS H20 correctly — drive selection, memory tier, optional HA, and networking cards — is where most procurement teams need a hand. Tell us your workload and capacity target and we’ll configure the right H20 and stay on the order until it ships.
- Configuration guidance from people who know TrueNAS
- Authorized-reseller pricing, without the procurement friction
- Order follow-through — from PO to delivery
Technical Specifications
Hardware metrics from the official TrueNAS datasheet.
-
PlatformTrueNAS H20
-
Form Factor2U rackmount
-
Controller10 Core (20 Threads)
-
RAM (Max)128–256 GB
-
Read Cache (Max)2× 3.2 TB NVMe SSD
-
Write CacheNVMe SSD
-
Drive Bays12× 3.5″/2.5″ (front-loading, hot swap)
-
Storage TypeHybrid or All-Flash (optional)
-
High AvailabilityOptional dual controller
-
Max Throughput4 GByte/s
-
Max Storage (Raw)3 PB
-
Max Effective Hybrid6 PB
-
Max NVMe Flash (Raw)360 TB
-
Max Effective NVMe Flash720 TB
-
Onboard Ethernet4× 1G Base-T
-
Additional Networking (Optional)Up to 4× 10/25 GbE
-
Fibre Channel2× 16 Gb
-
Expansion Shelves1× ES24, ES60, or ES102
-
Average Power Draw300 Watts
-
Peak Power Draw350 Watts
-
Heat Output1000 BTU/h
-
Dimensions (L × W × H)26.8″ × 19″ × 3.5″ | 681 × 483 × 89 mm
-
Rackmount Rails23″–35.75″ standard
-
Operating Temperature0°C to 40°C
-
Non-operating Temperature-30°C to 60°C
-
Humidity8% to 80% non-condensing
-
Empty Weight43 lbs | 19.5 kg
-
Fully-Loaded Weight67 lbs | 30.4 kg
-
ComplianceRoHS 6/6 compliant, CE, FCC Class A, VCCI, UL, BSMI
-
File ProtocolsSMB v1/2/3, NFSv3/v4, FTP, WebShare
-
Block ProtocolsiSCSI, Fibre Channel, NVMe-oF, OpenStack Cinder
-
Object ProtocolsS3-compliant
-
Directory ServicesActive Directory, FreeIPA, Kerberos, LDAP, NIS
-
File SystemOpenZFS — self-healing, immutable snapshots, RAID-Z1/Z2/Z3, dRAID
-
High AvailabilityAvailable dual controller support, automated rapid failover without data loss, virtual IP address migration
-
TrueSecure SecurityFIPS 140, NIST 800-209, GPOS STIG, KMIP key management, encrypted drives and datasets
-
Cloud BackupiX-Storj, Amazon S3, Backblaze B2, Google Cloud, Microsoft Azure
-
Backup IntegrationSupports Asigra, Acronis, Veeam, Nakivo, NetBackup, and more
Compare TrueNAS H-Series Models
Select the right scale for your storage workload.
| Model | Max Throughput | Max Raw Capacity | Networking | Action |
|---|---|---|---|---|
| TrueNAS H10 | 2 GB/s | 1.8 PB raw | Up to 4× 10/25 GbE | View |
| TrueNAS H20 This model | 4 GB/s | 3 PB raw | Up to 4× 10/25 GbE | Current |
| TrueNAS H30 | 8 GB/s | 3 PB raw | Up to 4× 10/25 GbE + 2× 40/100 GbE | View |
Frequently asked questions
The TrueNAS H20 is a 2U NVMe-accelerated hybrid NAS with a 10-core controller, 4 GB/s throughput, TrueCache NVDIMM, and up to 4× 10/25 GbE networking. The midrange H-Series model.
CPU and throughput scale through the H-Series: H10 is 4 cores at 2 GB/s, H20 is 10 cores at 4 GB/s, H30 is 20 cores at 8 GB/s. All three share the same chassis, networking baseline, and TrueCache NVDIMM acceleration.
Up to 3 PB raw capacity, the same ceiling as the H30. The H10 sizes a step lower at 1.8 PB raw.
Up to 4× 10/25 GbE. For workloads that need 40/100 GbE on top, the H30 extends the same baseline with 2× 40/100 GbE.
VM block storage, latency-sensitive file shares, mid-market backup repositories where NVMe acceleration matters but the H30's 20-core compute is more than needed.
