TrueNAS R-Series · Powerful Single Controller Storage

TrueNAS R60

Storage Type: All-Flash NVMe
Form Factor: 1U–17U scalable
CPU: 16–32 Cores
Memory: 192–384 GB DDR5
Drive Bays: 12× NVMe
Networking: 2× 400 GbE or 4× 25/100/200 GbE
Max Throughput: 60 GB/s
Max Raw Capacity: 7 PB

Request Pricing View Datasheet

Overview

The TrueNAS R60 pushes the boundaries of the R-Series by introducing next-generation performance for the most demanding modern workloads. Built with PCIe Gen5 capabilities and DDR5 RAM, the R60 is the first platform in the R-Series to leverage Terabit Ethernet technology, supporting speeds up to 400 GbE.

This all-flash powerhouse is engineered to deliver up to 60 GB/s of throughput with ultra-low latency, providing a high-performance foundation for AI, data science, and high-resolution video production while maintaining the series' signature focus on density and value. With up to 4 expansion shelves and 60 total NVMe drives, the R60 scales to 7 PB raw and 14 PB effective capacity.

Features and Benefits

The capabilities that make the TrueNAS R60 the next-generation all-flash platform in the R-Series — PCIe Gen5, Terabit Ethernet, and 60 GB/s throughput for AI, data science, and video production.

Next-Generation All-Flash Performance

PCIe Gen5, DDR5, Terabit Ethernet — 60 GB/s All-Flash Storage

The TrueNAS R60 is the first R-Series platform built with PCIe Gen5 and DDR5 RAM, delivering up to 60 GB/s of throughput with ultra-low latency. Supporting Terabit Ethernet at speeds up to 400 GbE, the R60 provides a high-performance foundation for AI inference, data science pipelines, and high-resolution video production workflows that demand both extreme throughput and low latency.

12× NVMe All-Flash Architecture

Twelve dedicated NVMe drive bays eliminate spinning disk entirely, delivering consistent ultra-low latency and high IOPS for AI, analytics, and real-time media workflows that cannot tolerate HDD seek times.

Advanced Data Protection

Features self-healing OpenZFS file system with copy-on-write, automatic bit-rot detection, built-in RAID protection, unlimited snapshots, and resilient replication to safeguard data integrity at all-flash speeds.

Terabit-Class Networking

2× 400 GbE

Dual 400 GbE ports deliver the highest per-port bandwidth in the R-Series — enabling 800 Gb/s aggregate throughput for GPU cluster interconnects and AI data pipelines.

4× 25/100/200 GbE Alternative

An alternative four-port configuration at 25, 100, or 200 GbE provides flexibility for existing 100/200 GbE switching infrastructure while maximizing port-count for multi-host connectivity.

2× 1GBase-T Management

Dedicated out-of-band 1G management ports keep data and management traffic separated for security and operational clarity.

Flexible Integration

Compatible with major virtualization hypervisors and backup software, and offers a fully-featured REST API. S3-compliant object storage using MinIO AIStor enables scale-out cluster deployments.

Scalable All-Flash Architecture

1U–17U Scalable Chassis — 7 PB Raw in a Single Namespace

The TrueNAS R60 scales from a compact 1U head unit to a 17U fully-expanded configuration with up to 4 expansion shelves and 60 total NVMe drives, delivering 7 PB raw and 14 PB effective capacity. The scalable chassis maintains all-flash performance characteristics at every expansion tier — no spinning disk compromise as you grow.

Cost-Effective Performance

The R60 optimizes per-dollar performance and scalability, delivering enterprise-grade all-flash storage solutions without compromising on quality or breaking the budget — the R-Series' signature value proposition applied to next-generation hardware.

TrueSecure Security

FIPS 140 for data-at-rest and data-in-flight, NIST 800-209, GP-OS STIG, KMIP key management, and encrypted drives and datasets protect all data stored on the R60's NVMe pool end-to-end.

View all features in the datasheet

Authorized TrueNAS Reseller

More than a price tag

The R60's PCIe Gen5 and 400 GbE options require matching infrastructure decisions — switch fabric, NVMe drive selection, and chassis expansion planning. Tell us your AI or video production workload requirements and we'll configure the right R60 and stay on the order until it ships.

Configuration guidance from people who know TrueNAS
Authorized-reseller pricing, without the procurement friction
Order follow-through — from PO to delivery

Talk to a Specialist View Datasheet

Technical Specifications

Hardware metrics from the official TrueNAS datasheet.

Platform

TrueNAS R60
Storage Type

All-Flash
Form Factor

1U–17U scalable
Chassis Depth

33″, 840 mm
Controllers

Single
Drive Bays

12× NVMe
CPU per Controller

16–32 Cores
DRAM per Controller

192–384 GB DDR5
Cache

N/A (all-flash, no separate cache tier)
Platform Generation

PCIe Gen5, DDR5

Max Throughput

60 GB/s
Max Raw Capacity

7 PB
Max Effective Capacity

14 PB
Max Drives Supported

60
Expansion Shelves

Up to 4

High-Speed Networking

2× 400 GbE or 4× 25/100/200 GbE
Management Networking

2× 1GBase-T
Fibre Channel

N/A

File Protocols

SMB v1/2/3, NFSv3/v4/RDMA, FTP, WebShare
Block Protocols

iSCSI, iSER, NVMe-oF, OpenStack Cinder
Object Protocols

S3-compliant using MinIO AIStor (single node, clustered)
Directory Services

Active Directory, FreeIPA, Kerberos, LDAP, NIS
File System

OpenZFS — self-healing, immutable snapshots, RAID-Z1/Z2/Z3, dRAID
TrueSecure Security

FIPS 140, NIST 800-209, GP-OS STIG, KMIP key management, encrypted drives and datasets
Cloud Backup

iX-Storj, Amazon S3, Backblaze B2, Google Cloud, Microsoft Azure
Backup Integration

Supports Asigra, Acronis, Veeam, Nakivo, NetBackup, and more

View datasheet for full specs

Compare TrueNAS R-Series Models

Select the right scale for your storage workload.

TrueNAS R-Series model comparison by throughput, capacity, and networking.
Model	Max Throughput	Max Raw Capacity	Networking	Action
TrueNAS R20	8 GB/s	3.4 PB raw	2× 10/25/40/100 GbE	View
TrueNAS R50	10 GB/s	6.5 PB raw	2× 10/25/40/100 GbE	View
TrueNAS R60 This model	60 GB/s	7 PB raw	2× 400 GbE or 4× 25/100/200 GbE	Current

R20 vs R50: deeper buyer guide

Frequently asked questions

The TrueNAS R60 is an all-NVMe single-controller rackmount NAS with 12 bays, 60 GB/s throughput, up to 7 PB raw capacity, and 2× 400 GbE networking. Runs TrueNAS Enterprise + OpenZFS.

60 GB/s — the highest in the single-controller R-Series, matching the V-Series ceiling but at a single-controller price point.

The R60 is single-controller; the V160 is hyperconverged with optional dual-controller HA. Both hit 60 GB/s and 400 GbE. Pick R60 for cost, V160 for HA and scale-out.

2× 400 GbE or 4× 25/100/200 GbE — built for NVMe-oF over RDMA workloads.

AI/ML inference datasets, scale-out lakehouse nodes, post-production shared NVMe, and any workload where single-controller is acceptable but high IOPS and bandwidth are required.
