iXsystems iX-5208G (Gen 4)
5U Dual Intel Xeon GPU Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the iX-5208G, which features a 5U form factor, a dual Intel Xeon LGA 4677 scalable gen4 processor, 32 DIMM slots with support for up to 8TB of total memory, and dual 10GbE network connectivity. The iX-5208G also provides flexible storage options, including eight 2.5” SATA/SAS/NVMe drive bays. Additionally, the server is equipped with twelve PCI-E 5.0 x16 slots, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- Research Laboratory/National Laboratory
- Animation and Modeling
- AI Inference and Machine Learning
- Autonomous Vehicle Technologies
- Molecular Dynamics Simulation
- 32 DIMM Slots – Up to 8 TB total memory
- 8 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays
- NVIDIA HGX H100 with 8 x SXM5 GPUs
- Up to 900GB/s GPU to GPU Interconnection
- 12 x PCI-E 5.0 x16 Slots
|Processor Support||Dual Intel Xeon LGA 4677 Scalable Gen4 Processors (Sapphire Rapids)|
|Chipset||Intel C741 Chipset|
|System Memory (Max.)||UUp to 8 TB Registered ECC DDR5 4800MHz SDRAM; 32 DIMM Slots|
|Networking||Dual 10GbE X710-AT2|
|PCIe Networking Options||Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available|
|VGA/BMC||ASPEED AST2600 BMC|
|Remote Management||Redfish API, IPMI 2.0; KVM with Dedicated LAN|
|Form Factor||5U Rackmount|
|Dimensions||945mm x 447mm x 222.25mm|
|Onboard Storage Controller||Intel SATA (6 Gbps) Controller + NVMe Controller|
|RAID Controller Options||Optional Hardware RAID or SAS HBA Available|
|Drive Bays||8 x 2.5” Hot-Swap|
|Expansion Slots||8 x PCI-E 5.0 x16 LP (from PEX89104)
4 x PCI-E 5.0 x16 LP
1 x PCI-E 4.0 x16 LP
|Power Supply||6 x 3000W Redundant High-Efficiency Power Supplies with I2C & PMBus|
- Pricing and product availability subject to change without notice.
