iXsystems iX-1212A (Gen 4)
1U Dual Intel Xeon Scalable Processors Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the iX-1212A, which features a 1U form factor, a dual Intel Xeon LGA 4677 scalable gen4 processor, 32 DIMM slots with support for up to 4TB of total memory, and dual 10GbE network connectivity. The iX-1212A also provides flexible storage options, including 12 x 2.5” SATA/SAS/NVMe drive bays. Additionally, the server is equipped with two PCI-E 5.0 x16 slots, one PCI-E 5.0 x16 OCP slot, one PCI-E 5.0 x16 LP slot, and two M.2 slots, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- CDN, Edge Nodes
- Gateway, provisioning servers
- Cloud Computing
- 32 DIMM Slots – Up to 4 TB Total Memory
- 12 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays
- 2 x PCI-E 5.0 x16 Slots
- 1 x PCI-E 5.0 x16 OCP
- 1 x PCI-E 5.0 x16 LP Slot
- 2 x M.2 Slots
|Processor Support||Dual Intel Xeon LGA 4677 Scalable Gen4 Processors (Sapphire Rapids)|
|Chipset||Intel C741 Chipset|
|System Memory (Max.)||Up to 4 TB Registered ECC DDR5 4800MHz SDRAM; 32 DIMM Slots|
|Networking||Dual 10GbE X710-AT2|
|PCIe Networking Options||Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available|
|VGA/BMC||ASPEED AST2600 BMC|
|Remote Management||Redfish API, IPMI 2.0; KVM with Dedicated LAN|
|Form Factor||1U Rackmount|
|Dimensions||842.5mm x 439.5mm x 44mm|
|Onboard Storage Controller||Intel SATA (6 Gbps) Controller + NVMe Controller|
|RAID Controller Options||Optional Hardware RAID or SAS HBA Available|
|Drive Bays||12 x 2.5” Hot-Swap|
|Expansion Slots||2 x PCI-E 5.0 x16 FHFL
1 x PCI-E 5.0 x18 LP HHHL
1 x PCI-E 5.0 x16 OCP
|Power Supply||2 x 1600W Redundant High-Efficiency Power Supplies with I2C & PMBus|
*SAS support only from optional SAS HBA/RAID card.
- Pricing and product availability subject to change without notice.
