iXsystems AX-22X424G (Gen 4)
2U 4-Node Dual AMD EPYC Processors Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the AX-22X424G, which features a 2U form factor, a dual AMD EPYC 9004 processor, 24 DIMM slots with support for up to 24TB of total memory, and dual 1GbE network connectivity. The AX-22X424G also provides flexible storage options, including six 2.5” SATA/NVMe drive bays. Additionally, the server is equipped with two PCI-E 5.0 x16 slots and one M.2 slot, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- All-Flash NVMe Hyperconverged Infrastructure
- High-Performance File System
- Diskless HPC Clusters
- Container-as-a-Service; Application Accelerator
- Compute Intensive Application
- 24 DIMM Slots Per Node – Up to 24 TB total memory
- 6 x 2.5” Hot-swap NVMe/SATA Drive Bays Per Node
- 2 x PCI-E 5.0 x16 Slots Per Node
- 1 x M.2 Slots Per Node
|Processor Support||Each node (1 of 4): Dual AMD EPYC 9004 (Genoa) Series Processor|
|Chipset||AMD EPYC System on Chip (SoC)|
|System Memory (Max.)||Each node (1 of 4): Up to 6TB ECC 3DS LRDIMM, Up to DDR5-4800Mhz; 24 DIMM Slots per Node|
|Networking||Dual 1GbE i350-AM2|
|PCIe Networking Options||Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available|
|VGA/BMC||Each node (1 of 4): Aspeed AST2600 BMC|
|Remote Management||Each node (1 of 4): Redfish API, IPMI 2.0; KVM with Dedicated LAN|
|Form Factor||2U Rackmount|
|Dimensions||877mm x 440mm x 87.5mm|
|Onboard Storage Controller||Each node (1 of 4): Gen 4 NVMe/SATA via AMD CPU|
|RAID Controller Options||Optional SAS HBA Available|
|Drive Bays||Each node (1 of 4): 6 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays|
|Expansion Slots||Each node (1 of 4):
2 x PCI-E 5.0 LP x16 LP
1 x PCI-E 5.0 x16 OCP
|Power Supply||2 x 3000W Redundant High-Efficiency Power Supplies with I2C & PMBus|
- Pricing and product availability subject to change without notice.
