iXsystems AX-2106A (Gen 4)
2U Single AMD EPYC Processor Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the AX-2106A, which features a 2U form factor, a single AMD EPYC 9004 processor, 12 DIMM slots with support for up to 3TB of total memory, and dual 1GbE network connectivity. The AX-2106A also provides flexible storage options, including four 3.5”/2.5” SATA/SAS/NVMe drive bays and two additional 3.5”/2.5” SATA/SAS bays. Additionally, the server is equipped with four dual FHFL GPU slots and one PCI-E 5.0 x16 OCP slot, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- AI Deep Learning Training and Inference
- Research Laboratory/National Laboratory
- Cloud Computing
- Autonomous Vehicle Technologies
- Molecular Dynamics Simulation
- 12 DIMM Slots – Up to 3 TB total memory
- 4 x 3.5”/2.5” Hot-Swap NVMe/SATA/SAS drive bays + 2 x 3.5”/2.5” Hot-Swap SATA/SAS Drive Bays
- 4 x Dual FHFL GPU Slots
- 1 x PCI-E 5.0 x16 OCP
|Processor Support||Single AMD EPYC 9004 (Genoa) Series Processor|
|Chipset||AMD EPYC System on Chip (SoC)|
|System Memory (Max.)||Up to 3 TB Registered ECC DDR5 4800MHz SDRAM; 12 DIMM Slots|
|Networking||Dual 1GbE i350-AM2|
|PCIe Networking Options||Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available|
|VGA/BMC||ASPEED ASMB11-iKVM BMC|
|Remote Management||Redfish API, IPMI 2.0; KVM with Dedicated LAN|
|Form Factor||2U Rackmount|
|Dimensions||800mm x 439.5mm x 88.9mm|
|Onboard Storage Controller||SATA (6 Gbps) Controller + NVMe Controller|
|RAID Controller Options||Optional Hardware RAID or SAS HBA Available|
|Drive Bays||6 x 3.5/2.5” Hot-Swap|
|Expansion Slots||4 x PCI-E 5.0 x16 Slots FHFL for Dual-Slot GPU Cards or
8 x PCI-E 5.0 x8 Slots FHFL for Single-Slot GPU Cards
1 x PCI-E 5.0 x16 Slots FHHL
1 x PCI-E 5.0 x8 Slot FHHL or OCP Socket Option or M.2 Riser Module
1 x PCI-E 5.0 x8 Slot LPHL
|Power Supply||2 x 2600W Redundant High-Efficiency Power Supplies with I2C & PMBus|
- Pricing and product availability subject to change without notice.
