1U Dual AMD Virtualization Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the AX-1212V, which features a 1U form factor, a dual AMD EPYC 7543 processor, 32 DIMM slots with support for up to 256GB/512GB of total memory, and dual 10GbE network connectivity. The AX-1212V also provides flexible storage options, including 12 x 2.5” hot-swap NVMe drive bays. Additionally, the server is equipped with two PCI-E 5.0 x16 slots, one PCI-E 5.0 x16 OCP and two M.2 slots, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- Cloud Computing
- High-End Enterprise Server
- DB Processing & Storage
- Data Center Applications
- Firewall Applications
- 32 DIMM Slots
- 12 x 2.5” Hot-Swap NVMe Bays in 1U
- 2 x M.2 Slots
- 2 x PCIe Slots
- GPU Option
|Processor Support||AMD EPYC 7543 Processor 32-Core 2.80GHz 256MB Cache (225W) Up to 2 x Processors for up to 64 Cores|
|Chipset||AMD 3rd Gen EPYC System on Chip (SoC)|
|System Memory (Max.)||256GB/512GB DDR4 3200Mhz ECC/REG Memory (Upgradable to 1 TB or 2 TB)|
|Networking||Dual Port Intel X710-AT2 10 Gigabit LAN Controller + 1 x Management LAN|
|Networking Options||2 x 10GbE (Default), 4 x 25GbE or 4 x 100GbE (Optional)|
|VGA/Audio||Aspeed AST2600 with 64MB VRAM|
|Remote Management||Integrated IPMI 2.0 with Virtual Media over LAN and KVM-over-LAN Dedicated LAN port|
|Form Factor||1U Rackmount|
|Dimensions||33.17” x 17.68” x 1.73”
842.5mm x 449mm x 43.85mm (1U)
|Onboard Storage Controller||LSI/Broadcom 8-Port Int. (16-Port Optional) 12Gb/s - support for Tri mode SATA+SAS+PCIe (NVMe) PCI-e 4.0 x8, 4GB RAM DDR4|
|RAID Controller Options||LSI Hardware RAID 1 Pre-configurerd|
|Drive Bays||12-Bay Hot-Swap 2.5” NVMe/SAS/SATA, 2 x 480GB SATA 2.5” Solid State Drives configured in a RAID1|
|Expansion Slots||2 x PCIe Gen4 x16, FHFL for Optional 100GbE, 40GbE, 25GbE or 10GbE Networking|
|Power Supply||1600W Redundant (1+1) Power Supply|
*If PCIe M.2 in use, this slot will drop to x8 link.
- Pricing and product availability subject to change without notice.
