iXsystems AX-1212A (Gen 4)
1U Dual AMD EPYC Processor Server
Get a Quote!
The iXsystems iX Series is a line of enterprise-grade rackmount servers designed to deliver reliable performance, versatility, and scalability for a wide range of workloads. The iX Series includes servers with various configurations, such as the AX-1212A, which features a 1U form factor, a dual AMD EPYC 9004 processor, 24 DIMM slots with support for up to 6TB of total memory, and quad 1GbE network connectivity. The AX-1212A also provides flexible storage options, including 12 x 2.5” SATA/SAS/NVMe drive bays. Additionally, the server is equipped with two PCI-E 5.0 x16 slots, one PCI-E 5.0 x16 OCP slot, and two M.2 slots, allowing for expandability and customization based on the needs of the deployment. Overall, the iXsystems iX Series servers are built to offer robust performance and efficiency for modern data centers and IT environments.
- Cloud Computing
- High End Enterprise Server
- AI Inference and Machine Learning
- Data Center Applications
- Software-defined Storage
- 24 DIMM Slots – Up to 6 TB Total Memory
- 12 x 2.5” Hot-Swap NVMe/SATA/SAS Drive Bays
- 2 x PCI-E 5.0 x16 Slots
- 1 x PCI-E 5.0 x16 OCP
- 2 x M.2 Slots
|Processor Support||Dual AMD EPYC 9004 (Genoa) Series Processor|
|Chipset||AMD EPYC System on Chip (SoC)|
|System Memory (Max.)||Up to 6 TB Registered ECC DDR5 4800MHz SDRAM; 24 DIMM Slots|
|Networking||Quad 1GbE i350-AM4|
|PCIe Networking Options||Optional 10GbE, 25GbE, 40GbE, 100GbE Ports Available|
|VGA/BMC||ASPEED AST2600 BMC|
|Remote Management||Redfish API, IPMI 2.0; KVM with Dedicated LAN|
|Form Factor||1U Rackmount|
|Dimensions||842.5mm x 449mm x 43.85mm|
|Onboard Storage Controller||SATA (6 Gbps) Controller + NVMe Controller|
|RAID Controller Options||Optional Hardware RAID or SAS HBA Available|
|Drive Bays||12 x 2.5” Hot-Swap|
|Expansion Slots||2 x PCI-E 5.0 x16 FHFL or 1 PCI-E 5.0 x16 FHFL w/ OCP
1 x PCI-E 5.0 x16 LP
1 x PCI-E 5.0 x8 LP
1 x PCI-E 5.0 x16 OCP
|Power Supply||2 x 1600W Redundant High-Efficiency Power Supplies with I2C & PMBus|
*SAS support only from optional SAS HBA/RAID card.
- Pricing and product availability subject to change without notice.
